以下内容详细列举博图各个版本对电脑的硬件和软件要求。
一、博图STEP7 Basic V10.5 对电脑配置要求
硬件要求
操作系统 微处理器 (最小) RAM (最小) 分辨率 (最小) MS Windows XP SP3 / MS Windows Vista SP1 Pentium 4, 1.7 GHz or comparable 1 GB 1024*768
软件要求
STEP 7 Basic V10.5 可用于下列操作系统:
Microsoft Windows XP Home SP3
Microsoft Windows XP Professional SP3
Microsoft Windows Vista Home Premium SP1
Microsoft Windows Vista Business SP1
Microsoft Windows Vista Ultimate SP1
与其它 SIMATIC 软件的兼容性:
STEP 7 Basic V10.5 (包含 WinCC Basic V10.5) 可以与以下软件兼容:
STEP 7
STEP 7 Micro/WIN
WinCC flexible (2008 或更高)
WinCC (V6.2 SP3 或更高).
STEP 7 Basic V10.5 SP2 可用于下列操作系统:
Microsoft Windows XP Home SP3
Microsoft Windows XP Professional SP3
Microsoft Windows Vista Home Premium SP1
Microsoft Windows Vista Business SP1
Microsoft Windows Vista Ultimate SP1
安装 STEP 7 V10.5 SP2 的前提条件：
STEP 7 V10.5 (带或不带 SP1)
Pentium 4, 1.7 GHz 或类似
1 GB 内存或更大
屏幕分辨率为 1024x768 或以上
二、博图V11
硬件要求
安装 STEP 7 Basic / Professional V11 的计算机必须至少满足以下需求:
处理器： Core 2 DUO 2.4 GHz 或者相当
内存： 2 GB 或更高
硬盘：250GB
图形分辨率：1400 x 1050
显示器：15"
软件要求
STEP 7 Professional / Basic V11 可以安装于以下操作系统
Windows 7操作系统，32位
Windows 7 Home Premium *
Windows 7 Professional
Windows 7 Enterprise
Windows 7 Ultimate
Windows XP 操作系统
Windows XP Professional SP3
Windows Home SP3 *
Windows Server，32位
Server 2008 Standard SP2 **
Server 2003 R2 Standard SP2 **
Server 2003 Standard SP2 **
STEP 7 Professional / Basic V11 SP1 可以安装于以下操作系统
Windows 7操作系统，32位
Windows 7 Home Premium SP1 *
Windows 7 Home Premium *
Windows 7 Professional SP1
Windows 7 Professional
Windows 7 Enterprise SP1
Windows 7 Enterprise
Windows 7 Ultimate SP1
Windows 7 Ultimate
Windows XP 操作系统
Windows XP Professional SP3
Windows Home SP3 *
Windows Server，32位
Server 2008 Standard SP2 **
Server 2003 R2 Standard SP2 **
Server 2003 Standard SP2 **
STEP 7 Professional / Basic V11 SP2 可以安装于以下操作系统
Windows 7操作系统，64位
Windows 7 Home Premium SP1 *
Windows 7 Professional SP1
Windows 7 Enterprise SP1
Windows 7 Ultimate SP1
Windows 7操作系统，32位
Windows 7 Home Premium SP1 *
Windows 7 Home Premium *
Windows 7 Professional SP1
Windows 7 Professional
Windows 7 Enterprise SP1
Windows 7 Enterprise
Windows 7 Ultimate SP1
Windows 7 Ultimate
Windows XP 操作系统
Windows XP Professional SP3
Windows Home SP3 *
Windows Server
Server 2008 R2 Standard 64位 SP1 **
Server 2008 R2 Standard 64位 **
Server 2008 Standard 32位 SP2 **
Server 2003 R2 Standard 32位 SP2 **
Server 2003 Standard 32位 SP2 **
三、博图V12
硬件要求
安装 STEP 7 Basic / Professional V12 的计算机必须至少满足以下需求：
处理器： Core i5, 2.4 GHz 或者相当
内存： PC/PG 安装32位操作系统时为3GBPC/PG 安装64位操作系统时为8GB
硬盘：250 GB S-ATA HDD
图形分辨率：最小 1280x1024
显示器：15" SXGA + Display (1400 x 1050)
软件要求
STEP 7 Professional / Basic V12 可以安装于以下操作系统
Windows 7操作系统，64位
Windows 7 Home Premium SP1 *
Windows 7 Home Premium *
Windows 7 Professional SP1
Windows 7 Professional
Windows 7 Enterprise SP1
Windows 7 Enterprise
Windows 7 Ultimate SP1
Windows 7 Ultimate
Windows 7操作系统，32位
Windows 7 Home Premium SP1 *
Windows 7 Home Premium *
Windows 7 Professional SP1
Windows 7 Professional
Windows 7 Enterprise SP1
Windows 7 Enterprise
Windows 7 Ultimate SP1
Windows 7 Ultimate
Windows XP 操作系统
Windows XP Professional SP3
Windows Home SP3 *
Windows Server
Server 2008 R2 Standard 64位 SP1 **
Server 2008 R2 Standard 64位 **
Server 2008 R2 Standard 32位 SP2 **
Server 2003 R2 Standard 32位 SP2 **
STEP 7 Professional / Basic V12 SP1可以安装于以下操作系统
Windows 7操作系统，64位
Windows 7 Home Premium SP1 *
Windows 7 Professional SP1
Windows 7 Enterprise SP1
Windows 7 Ultimate SP1
Windows 7操作系统，32位
Windows 7 Home Premium SP1 *
Windows 7 Professional SP1
Windows 7 Enterprise SP1
Windows 7 Ultimate SP1
Windows XP 操作系统
Windows XP Professional SP3
Windows Home SP3 *
Windows Server，64位
Server 2008 R2 Standard Edition 64位 SP1 **
Server 2008 R2 Standard Edition 64位 **
四、博图V13
硬件要求
安装 STEP 7 Basic / Professional V13 的计算机必须至少满足以下需求:
处理器： Core i5-3320M 3.3 GHz 或者相当
内存： 至少8G
硬盘：300 GB SSD
图形分辨率：最小 1920 x 1080
显示器：15.6" 宽屏显示 (1920 x 1080)
软件要求
STEP 7 Professional / Basic V13/V13 SP1可以安装于以下操作系统
Windows 7操作系统，64位
Windows 7 Home Premium SP1 *
Windows 7 Professional SP1
Windows 7 Enterprise SP1
Windows 7 Ultimate SP1
Windows 7操作系统，32位
Windows 7 Home Premium SP1 *
Windows 7 Professional SP1
Windows 7 Enterprise SP1
Windows 7 Ultimate SP1
Windows 8操作系统，64位
Microsoft Windows 8.1 Professional
Microsoft Windows 8.1 Enterprise
Windows Server(64位）
Server 2012 R2 Standard
Server 2008 R2 Standard SP1 **
STEP 7 Professional / Basic V13 SP2可以安装于以下操作系统
Windows 7操作系统，64位
Windows 7 Home Premium SP1 *
Windows 7 Professional SP1
Windows 7 Enterprise SP1
Windows 7 Ultimate SP1
Windows 8操作系统，64位
Microsoft Windows 8.1 Professional
Microsoft Windows 8.1 Enterprise
Windows 10操作系统（64位）
Windows 10 Home Version 2004 * ****
Windows 10 Home Version 1909 * ***
Windows 10 Home Version 1903 * ***
Windows 10 Home Version 1809 * ***
Windows 10 Home Version 1803 * ***
Windows 10 Home Version 1607 *
Windows 10 Professional Version 2004 ****
Windows 10 Professional Version 1909 ***
Windows 10 Professional Version 1903 ***
Windows 10 Professional Version 1809 ***
Windows 10 Professional Version 1803 ***
Windows 10 Professional Version 1607
Windows 10 Enterprise Version 2004 ****
Windows 10 Enterprise Version 1909 ***
Windows 10 Enterprise Version 1903 ***
Windows 10 Enterprise Version 1809 ***
Windows 10 Enterprise Version 1803 ***
Windows 10 Enterprise Version 1607
Windows 10 Enterprise LTSC 2019 ***
Windows 10 Enterprise LTSC 2016
Windows 10 Enterprise LTSC 2015
Windows Server(64位）
Windows Server Standard 2004 ****
Windows Server Standard 1909 ***
Windows Server Standard 1903 ***
Windows Server Standard 1809 ***
Windows Server Standard 1803 ***
Windows Server 2016 Standard
Windows Server 2012 R2 Standard
Windows Server 2008 R2 Standard SP1 **
五、博图V14
硬件要求
安装 STEP 7 Basic / Professional V14 的计算机必须至少满足以下需求:
处理器： Core i5-6640EQ 3.4 GHz 或者相当
内存： 16 GB 或更高（大项目为 32 GB）
硬盘：SSD，至少 50GB 可用存储空间
图形分辨率：最小 1920 x 1080
显示器：15.6" 宽屏显示 (1920 x 1080)
软件要求
STEP 7 Professional / Basic V14 可以安装于以下操作系统
Windows 7操作系统，64位
Windows 7 Home Premium SP1 *
Windows 7 Professional SP1
Windows 7 Enterprise SP1
Windows 7 Ultimate SP1
Windows 8操作系统，64位
Microsoft Windows 8.1 Professional
Microsoft Windows 8.1 Enterprise
Windows Server，64位
Server 2012 R2 Standard Edition
Server 2008 R2 Standard Edition SP1 **
STEP 7 Professional / Basic V14 SP1 可以安装于以下操作系统
Windows 7操作系统，64位
Windows 7 Home Premium SP1 *
Windows 7 Professional SP1
Windows 7 Enterprise SP1
Windows 7 Ultimate SP1
Windows 8操作系统，64位
Microsoft Windows 8.1 Professional
Microsoft Windows 8.1 Enterprise
Windows 10操作系统，64位
Windows 10 Home Version 20H2 * ****
Windows 10 Home Version 2004 * ****
Windows 10 Home Version 1909 * ****
Windows 10 Home Version 1903 * ****
Windows 10 Home Version 1809 * ***
Windows 10 Home Version 1803 * ***
Windows 10 Home Version 1607 *
Windows 10 Professional Version 20H2 ****
Windows 10 Professional Version 2004 ****
Windows 10 Professional Version 1909 ****
Windows 10 Professional Version 1903 ****
Windows 10 Professional Version 1809 ***
Windows 10 Professional Version 1803 ***
Windows 10 Professional Version 1607
Windows 10 Enterprise Version 20H2 ****
Windows 10 Enterprise Version 2004 ****
Windows 10 Enterprise Version 1909 ****
Windows 10 Enterprise Version 1903 ****
Windows 10 Enterprise Version 1809 ***
Windows 10 Enterprise Version 1803 ***
Windows 10 Enterprise Version 1607
Windows 10 Enterprise LTSC 2019 ***
Windows 10 Enterprise LTSC 2016
Windows 10 Enterprise LTSC 2015
Windows Server(64位）
Windows Server Standard 20H2 ****
Windows Server Standard 2004 ****
Windows Server Standard 1909 ****
Windows Server Standard 1903 ****
Windows Server Standard 1809 ***
Windows Server Standard 1803 ***
Windows Server 2016 Standard
Windows Server 2012 R2 Standard
Windows Server 2008 R2 Standard SP1 **
六、博图V15
硬件要求
安装 STEP 7 Basic / Professional V15 的计算机必须至少满足以下需求:
处理器： Core i5-6440EQ 3.4 GHz 或者相当
内存： 16GB或者更多（对于大型项目，为32GB)
硬盘：SSD，配备至少50GB的存储空间
图形分辨率：最小 1920 x 1080
显示器：15.6" 宽屏显示 (1920 x 1080)
软件要求
STEP 7 Professional / Basic V15 可以安装于以下操作系统
Windows 7操作系统 （64位）
Windows 7 Home Premium SP1 *
Windows 7 Professional SP1
Windows 7 Enterprise SP1
Windows 7 Ultimate SP1
Windows 10操作系统（64位）
Windows 10 Home Version 1809 * **
Windows 10 Home Version 1803 * **
Windows 10 Home Version 1703 *
Windows 10 Professional Version 1809 **
Windows 10 Professional Version 1803 **
Windows 10 Professional Version 1703
Windows 10 Enterprise Version 1809 **
Windows 10 Enterprise Version 1803 **
Windows Version 1703
Windows 10 Enterprise LTSC 2019 *
Windows 10 Enterprise LTSC 2016
Windows 10 Enterprise LTSC 2015
Windows Server(64位）
Windows Server Standard 1809 *
Windows Server Standard 1803 *
Windows Server 2016 Standard
Windows Server 2012 R2 Standard
七、博图V15.1
硬件要求
安装 STEP 7 Basic / Professional V15.1 的计算机必须至少满足以下需求:
处理器： Core i5-6440EQ 3.4 GHz 或者相当
内存： 16GB或者更多（对于大型项目，为32GB)
硬盘：SSD，配备至少50GB的存储空间
图形分辨率：最小 1920 x 1080
显示器：15.6" 宽屏显示 (1920 x 1080)
软件要求
STEP 7 Professional / Basic V15.1 可以安装于以下操作系统
Windows 11操作系统（64位）****
Windows 11 Home Version 21H2 *
Windows 11 Professional Version 21H2
Windows 11 Enterprise Version 21H2
Windows 10操作系统（64位）
Windows 10 Home Version 21H2 * ****
Windows 10 Home Version 21H1 * ***
Windows 10 Home Version 20H2 * **
Windows 10 Home Version 2004 * **
Windows 10 Home Version 1909 * **
Windows 10 Home Version 1903 * **
Windows 10 Home Version 1809 *
Windows 10 Home Version 1803 *
Windows 10 Home Version 1709 *
Windows 10 Professional Version 21H2 ****
Windows 10 Professional Version 21H1 ***
Windows 10 Professional Version 20H2 **
Windows 10 Professional Version 2004 **
Windows 10 Professional Version 1909 **
Windows 10 Professional Version 1903 **
Windows 10 Professional Version 1809
Windows 10 Professional Version 1803
Windows 10 Professional Version 1709
Windows 10 Enterprise Version 21H2 ****
Windows 10 Enterprise Version 21H1 ***
Windows 10 Enterprise Version 20H2 **
Windows 10 Enterprise Version 2004 **
Windows 10 Enterprise Version 1909 **
Windows 10 Enterprise Version 1903 **
Windows 10 Enterprise Version 1809
Windows 10 Enterprise Version 1803
Windows 10 Enterprise Version 1709
Windows 10 Enterprise LTSC 2021 ****
Windows 10 Enterprise LTSC 2019
Windows 10 Enterprise LTSC 2016
Windows 10 Enterprise LTSC 2015
Windows 7操作系统 （64位）
Windows 7 Home Premium SP1 *
Windows 7 Professional SP1
Windows 7 Enterprise SP1
Windows 7 Ultimate SP1
Windows Server(64位）
Windows Server Standard 21H2 ****
Windows Server Standard 21H1 ***
Windows Server Standard 20H2 **
Windows Server Standard 2004 **
Windows Server Standard 1909 **
Windows Server Standard 1903 **
Windows Server Standard 1809
Windows Server 2022 Standard ****
Windows Server 2019 Standard
Windows Server 2016 Standard
Windows Server 2012 R2 Standard
八、博图V16
硬件要求
安装 STEP 7 Basic / Professional V16 的计算机推荐满足以下需求:
处理器： Core i5-6440EQ 3.4 GHz 或者相当
内存： 16GB或者更多（对于大型项目，为32GB)
硬盘：SSD，配备至少50GB的存储空间
图形分辨率：最小 1920 x 1080
显示器：15.6" 宽屏显示 (1920 x 1080)
软件要求
STEP 7 Professional / Basic V16 可以安装于以下操作系统
Windows 11操作系统（64位）****
Windows 11 Home Version 21H2 *
Windows 11 Professional Version 21H2
Windows 11 Enterprise Version 21H2
Windows 10操作系统（64位）
Windows 10 Home Version 21H2 * *****
Windows 10 Home Version 21H1 * ****
Windows 10 Home Version 20H2 * ***
Windows 10 Home Version 2004 * **
Windows 10 Home Version 1909 * **
Windows 10 Home Version 1903 *
Windows 10 Home Version 1809 *
Windows 10 Professional Version 21H2 *****
Windows 10 Professional Version 21H1 ****
Windows 10 Professional Version 20H2 ***
Windows 10 Professional Version 2004 **
Windows 10 Professional Version 1909 **
Windows 10 Professional Version 1903
Windows 10 Professional Version 1809
Windows 10 Enterprise Version 21H2 *****
Windows 10 Enterprise Version 21H1 ****
Windows 10 Enterprise Version 20H2 ***
Windows 10 Enterprise Version 2004 **
Windows 10 Enterprise Version 1909 **
Windows 10 Enterprise Version 1903
Windows 10 Enterprise Version 1809
Windows 10 Enterprise LTSC 2021 *****
Windows 10 Enterprise LTSC 2019
Windows 10 Enterprise LTSC 2016
Windows 10 Enterprise LTSC 2015
Windows 7操作系统 （64位）
Windows 7 Home Premium SP1 *
Windows 7 Professional SP1
Windows 7 Enterprise SP1
Windows 7 Ultimate SP1
Windows Server(64位）
Windows Server Standard 21H2 *****
Windows Server Standard 21H1 ****
Windows Server Standard 20H2 ***
Windows Server Standard 2004 **
Windows Server Standard 1909 **
Windows Server 2022 Standard ****
Windows Server 2019 Standard
Windows Server 2016 Standard
Windows Server 2012 R2 Standard
九、博图V17
硬件要求
安装 STEP 7 Basic / Professional V17 的计算机推荐满足以下需求:
处理器： Intel® Core™ i5-8400H（2.5 到 4.2 GHz；4 核 + 超线程；8 MB 智能缓存）
内存： 16GB或者更多（对于大型项目，为32GB)
硬盘：SSD，配备至少50GB的存储空间
图形分辨率：最小 1920 x 1080
显示器：15.6" 宽屏显示 (1920 x 1080)
软件要求
STEP 7 Professional / Basic V17 可以安装于以下操作系统
Windows 11操作系统（64位）***
Windows 11 Home Version 21H2 *
Windows 11 Professional Version 21H2
Windows 11 Enterprise Version 21H2
Windows 10操作系统（64位）
Windows 10 Home Version 21H2 * **
Windows 10 Home Version 21H1 *
Windows 10 Home Version 20H2 *
Windows 10 Home Version 2004 *
Windows 10 Home Version 1909 *
Windows 10 Professional Version 21H2 **
Windows 10 Professional Version 21H1
Windows 10 Professional Version 20H2
Windows 10 Professional Version 2004
Windows 10 Professional Version 1909
Windows 10 Enterprise Version 21H2 **
Windows 10 Enterprise Version 21H1
Windows 10 Enterprise Version 20H2
Windows 10 Enterprise Version 2004
Windows 10 Enterprise Version 1909
Windows 10 Enterprise LTSC 2021 **
Windows 10 Enterprise LTSC 2019
Windows 10 Enterprise LTSC 2016
Windows Server(64位）
Windows Server Standard 21H2 **
Windows Server Standard 21H1
Windows Server Standard 20H2
Windows Server 2022 Standard ***
Windows Server 2019 Standard
Windows Server 2016 Standard
